PTO rear shaft upgrade ?

Kerryman

New member

Equipment
B7200 tractor & RCk54--22BX. Deck
Sep 28, 2024
1
1
1
Ireland
Hi guys. Do my orange is a b7200. Very clean for its age (better than me šŸ˜€) and I have fitted a mower deck to it, A 54ā€ Kubota deck RCk54--22BX via the rear 3 point linkage.
Only problem is the mower isnā€™t spinning fast enough to slice the grass. More like itā€™s pulling it. I have it set in high pto speed (825)) with the engine at 2800 revolutions (high). Running in 2nd low gear. The grass is getting cut but not right. Blades are super sharp.
My local dealer maintains I cannot change the pto shaft to increase the speed.
Any thoughts out there ???

I have a donkey who will eat the grass eventually šŸ˜€šŸ˜€šŸ˜€

  • Like
Reactions: 1 user

rc51stierhoff

Well-known member

Equipment
B2650, MX6000, Ford 8N, (BX sold)
Sep 13, 2021
2,438
2,887
113
Ohio
Good day.

I am not familiar with your machine at all. I wonder how do you know the blades arenā€™t spinning fast enough?

Blades are installed correct direction, correct? Belt tension good? All blades spin properly? Etc.


GreensvilleJay

Well-known member

Equipment
BX23-S,57 A-C D-14,58 A-C D-14, 57 A-C D-14,tiller,cults,Millcreek 25G spreader,
Apr 2, 2019
11,171
4,778
113
Greensville,Ontario,Canada
If I read this post correctly, you took the MMM and put it onto the 3PH ?

There are 2 issues when you did this.

1) RPM. MMM (front PTO) spins at 2000-2500 RPM, PTO is 540.

2) DIRECTION of rotation. the blades could be spinning backwards !

#2 is easy, #1 is pricey

#2 )pretty sure the PTO will spin CCW ( to the left, from 12oclock ) ? If so, MANUALLY spin the PTO shaft and see if the deck blades turn the CORRECT way.

#1 ) buy and install an 'increaser' gear box. Yes, they are available, or make your own. essentially a large gear powered by the PTO, that drives a smaller gear which powers the deck. A 4:1 ratio seems 'good'.


Sidekick

Well-known member

Equipment
Kioti CK2620SE cab, RTV-X, BX2360, Z726XKW-3-60
Jul 29, 2023
490
403
63
N.Y,
I think the BX mid pto spins at 2500 rpm at 3200 engine rpm. There's pto speed increasers available if you search. Also I have seen people switch the gearbox gears to the set from the zero turn to increase tip speed. Start increasing pto speed and hp will suffer with inefficiency. Probably be cheaper to find a used finish mower.


TheOldHokie

Well-known member
Lifetime Member

Equipment
L3901/LA525, B7200DT/B1630, G2160/RCK60, G2460/RCK60
Apr 6, 2021
8,391
4,248
113
Myersville, MD
windyridgefarm.us
Hi guys. Do my orange is a b7200. Very clean for its age (better than me šŸ˜€) and I have fitted a mower deck to it, A 54ā€ Kubota deck RCk54--22BX via the rear 3 point linkage.
Only problem is the mower isnā€™t spinning fast enough to slice the grass. More like itā€™s pulling it. I have it set in high pto speed (825)) with the engine at 2800 revolutions (high). Running in 2nd low gear. The grass is getting cut but not right. Blades are super sharp.
My local dealer maintains I cannot change the pto shaft to increase the speed.
Any thoughts out there ???

I have a donkey who will eat the grass eventually šŸ˜€šŸ˜€šŸ˜€
Your mid-mount mower wants 3X the 820 RPM of the B7200 rear PTO. Buy a 3pt finish mower. Its probably less expensive and definitly a lot easier than stepping up the drive ratio on the mower.

Dan

  • Like
Reactions: 1 user

GreensvilleJay

Well-known member

Equipment
BX23-S,57 A-C D-14,58 A-C D-14, 57 A-C D-14,tiller,cults,Millcreek 25G spreader,
Apr 2, 2019
11,171
4,778
113
Greensville,Ontario,Canada
aw, where's the fun in just spending $3K for a mower when you could build an increaser for less than $500 ? 3:1 is easy.
still wondering about the rotation though.


Sidekick

Well-known member

Equipment
Kioti CK2620SE cab, RTV-X, BX2360, Z726XKW-3-60
Jul 29, 2023
490
403
63
N.Y,
aw, where's the fun in just spending $3K for a mower when you could build an increaser for less than $500 ? 3:1 is easy.
still wondering about the rotation though.
But need to buy $2500 worth of tools to build one šŸ˜‰.


North Idaho Wolfman

Moderator
Staff member
Lifetime Member

Equipment
L3450DT-GST, Woods FEL, B7100 HSD, FEL, 60" SB, 743 Bobcat with V2203, and more
Jun 9, 2013
29,823
6,025
113
Sandpoint, ID
Simple answer, No it won't work!
No you can not change the tractor to be a higher PTO output speed.
