RTV 1120D glow plug relay location. Can't find it, any help greatly appreciated

Dave_eng

Well-known member
Lifetime Member

Equipment
M7040, Nuffield 465
Oct 6, 2012
4,640
642
113
Williamstown Ontario Canada
On a more serious note, looking at the Messicks parts stuff I see one 20 amp relay located as seen below.

forum RTV-X1120D relay.jpg


I have no idea if it is a Glow Plug relay or even if your machine would use a relay for the glow plugs as most are controlled by the key switch.

Relay is part number K7311-62310 for $16

Dave


whitetiger

Well-known member

Equipment
Kubota tech..BX2370, RCK60, B7100HST, RTV900 w plow, Ford 1100 FWA
Nov 20, 2011
1,882
561
113
Kansas City, KS
Can anyone point me to the glow plug relay on a RTV X 1120 D? Thanks
Look in your Operators manual, it shows pictures of lifting the seats, removing the tool tray, and the access cover where you will find the fuses and relays.

  • Like
Reactions: 1 user

sharrisc

New member

Equipment
X1120D
Oct 30, 2021
4
0
1
Temecula, California
Look in your Operators manual, it shows pictures of lifting the seats, removing the tool tray, and the access cover where you will find the fuses and relays.
Thanks, all fuses tested good-took the relays to dealer, they tested them as good. I noticed a relay under the hood, attached to the ignition switch harness, 20 amp, I think. Would that be it?
